Air Traffic Management

HDLC-ATC Air Traffic Data Communication Server

ATC radar data communication protocol converter
2, 3 Ethernet 100M ports
4, 8, 16 HDLC synchronous RS-232 serial ports
Serial, Ethernet bi-directional conversion
1U, 19-inch standard rackmount chassis
Dual power supply redundancy
Low power consumption, fanless design

HDLC-USB Portable Protocol Converter

For air traffic control, train, aerospace, transportation
1 Ethernet 100M port
2 RS-232/422/485 multi-protocol serial ports
Realize serial port, Ethernet conversion
Realize synchronous HDLC, asynchronous UART conversion
Slim and compact, support USB power supply.

HDLC-LCM Low Power Communication Module

For air traffic control, train, aerospace, industrial networks
+3.3V power supply, low power consumption embedded communication module
2 Ethernet 100M PHY interfaces
4 serial interfaces, support synchronous HDLC, asynchronous UART
Support NRZ, NRZI, DBPL, Manchester encoding
46.5 x 48 mm miniature size, 2.0mm pin interface

HDLC-ETH Serial Ethernet Converter

Compact Synchronous HDLC Protocol Converter
Suitable for ATC, aerospace measurement and traffic control
1, 2 Ethernet 100M interfaces
4 synchronous and asynchronous serial interfaces, optional RS-232 or RS-422/485
Serial port support synchronous HDLC, asynchronous UART
Realize serial port, Ethernet conversion

HDLC-RSD Synchronous Serial Port Splitter

Radar Data Distributor for ATC
Baud rate support 2400 ~ 250Kbps arbitrary rate
Support synchronous HDLC and asynchronous UART
Realize signal 1 divided into 4, 1 divided into 8
Support RS-232, RS-422
Support dual power supply redundancy

TECHNICAL DOCUMENTS

Design and Implementation of High-speed Serial Synchronous Communication

Design and Implementation of High-speed Serial Synchronous Communication

Design and Implementation of HDLC Synchronous Serial Port for ATC Radar

The ATC radar data network uses the HDLC protocol to transmit target data, and the ATC radar and ADS-B equipment must be able to support the HDLC protocol and provide multiple synchronized serial ports for outputting radar data.

Introduction to HDLC Protocol

HDLC protocol, sometimes known as SDLC protocol, is a link layer protocol widely used in industry communications. The HDLC protocol specification is referred to the ISO / IEC 13239 standard document.

Synchronous HDLC Application Based on RS-232 Interface

Synchronous HDLC Application Based on RS-232 Interface

The Selection and Configuration of Synchronization Clock for HDLC Protocol

Synchronous HDLC serial communication, different from ordinary asynchronous communication, the clock signal plays an important role, only the sender and receiver use the same clock, can achieve highly reliable data transmission.

Impact of ADS-B on the ATC radar data network

Due to the advantages of low station construction cost and high data refresh rate, ADS-B receivers have been applied in large scale in ATC system.
