Train Communication Network

HDLC-TCMS TCN Protocol Converter
  • Synchronous HDLC protocol converter for trains
  • 2 Ethernet 100M ports
  • Optional multiple RS-232/422/485 serial ports or CAN port
  • Serial port support HDLC protocol, UART mode
  • Realize serial port, CAN port, Ethernet port conversion
  • Industrial grade wide temperature, complete isolation protection
DETAILS
HDLC-UART Isolate Embedded Module
  • Train Embedded Communication Module
  • 2 RS-485/422 synchronous and asynchronous serial ports with isolation
  • 1 LVCMOS extension synchronous and asynchronous serial ports
  • All serial ports support synchronous HDLC protocol and asynchronous UART.
  • Realize HDLC, UART conversion each other
  • +5V power supply, 2.54mm pin interface
DETAILS
MVB-Gateway Protocol Conversion Gateway
  • 1 MVB interface, EMD media type
  • 1 Ethernet 100M port, 1 channel CAN port with isolation
  • 1 extended serial port, optional RS-232, RS-422, RS-485
  • Support MVB to Ethernet, CAN, serial port
  • Power supply options: 24V, 36V, 48V, 72V, 96V, 110V standard
  • Provide free configuration management software, MVB debugging software, quickly get started
DETAILS
MVB-CAN-UART MVB Embedded Module
  • 1 MVB interface, support EMD, ESD+
  • Support MVB slave protocol, multiple PD source ports and host ports
  • Support MVB bus PD data acquisition function
  • 1 UART expansion serial port, support serial to MVB
  • 1 CAN bus interface, support CAN to MVB
  • Small size, 2.54mm pin interface, +5V power supply
DETAILS
MVB-UDP Ethernet to MVB Embedded Module
  • 1 Ethernet 10/100M PHY interface
  • 1 UART extended serial port
  • Full feature MVB redundant interface, Support EMD, ESD+ interface, IEC61375 compliant
  • Supports MVB slave protocol, multiple PD source and sink ports
  • Supports PD data acquisition function of MVB-bus
  • +5V power supply, low power consumption
  • Small size, Industrial wide temperature
DETAILS
MVB-EMD Embedded Slave Network Card
  • 1 UART extended serial port
  • 1 MVB interface, EMD media type,support MVB slave protocol
  • Support multiple PD source ports and sink ports
  • Support MVB bus PD data acquisition function
  • + 5V power supply, Low power consumption
  • Small size, Industrial wide temperature
DETAILS
MVB-TCMS TCN Protocol Converter
  • 1 MVB interface, optional EMD, ESD media type
  • 2 Ethernet 100M port, support UDP to MVB
  • Extended interface R2-232, RS-422, RS-485, CAN optional, support for serial port to MVB
  • Optionally support TRDP protocol
  • Power supply options: 24V, 36V, 48V, 72V, 96V, 110V standard
  • Equipped with free and easy-to-use management software, MVB debugging software, quick to get started.
DETAILS
TRDP-Gateway Protocol Conversion Gateway
  • 2 Ethernet 100M full-duplex interfaces, support TRDP protocol
  • 1 Ethernet 100M adaptive interface, support TCP/IP protocol
  • X6 extended interface: optional RS-232, RS-422 or RS-485 serial port
  • X4 extended interface: CAN bus interface
  • Support TRDP PD acquisition function
  • Perfect isolation protection
  • Industrial wide temperature
DETAILS
TRDP-UDP Dual Redundant TRDP Embedded Module
  • 2 Ethernet 100M full-duplex interfaces, support TRDP protocol
  • 1 Ethernet 100M adaptive interface, support TCP/IP protocol
  • 1 UART serial port
  • 1 CAN bus interface
  • Support TRDP PD acquisition function
  • +3.3V power supply, low power consumption
  • Small size, industrial wide temperature
DETAILS
TRDP-MVB Dual Bus Communication Module
  • 2 Ethernet 100M full-duplex interfaces, support TRDP protocol
  • 1 MVB redundant interface, support MVB slave protocol
  • 1 serial port
  • 1 CAN bus interface
  • Open and flexible configuration management
  • +3.3V power supply, low power consumption
  • Small size, Industrial wide temperature
DETAILS
TRDP-CAN-UART Micro TRDP Embedded Module
  • 1 Ethernet 10/100M PHY, support TRDP
  • 1 UART extended serial port
  • 1 CAN bus interface
  • +3.3V power supply, low power consumption
  • Small size, industrial wide temperature
DETAILS
TRDP-ETH Dual Redundant TRDP Ethernet Card
  • 2 Ethernet 100M full-duplex interfaces, support TRDP protocol
  • 1 Ethernet 100M adaptive interface, support TCP/IP protocol
  • X6 extended interface: optional RS-232, RS-422 or RS-485 serial port
  • X4 extended interface: CAN bus interface
  • Supporting TRDP PD acquisition function
  • Perfect isolation protection, Industrial wide temperature
DETAILS
CAN-TCMS Protocol Conversion Gateway
  • 1 CAN bus interface with isolation
  • 1 Ethernet 10/100M interface
  • 1 extended serial port: optional RS-232, RS-422 or RS-485 serial port
  • Perfect isolation protection, industrial wide temperature
DETAILS
CAN-UART Micro CAN Embedded Module
  • 1 CAN bus interface
  • 1 UART extended serial port
  • + 3.3V power supply, Low power consumption
  • Small size, Industrial wide temperature
DETAILS
CAN-UDP Ethernet to CAN Embedded Module
  • 1 CAN bus interface;
  • 1 Ethenet 10/100M PHY
  • 1 UART extended serial port
  • + 3.3V power supply, Low power consumption
  • Small size, Industrial wide temperature
DETAILS
